Guangshengde Technology's automated production line technology solution provider, Guangshengde automatic chain plate line is sold all over the country and overseas.

1. Guangshengde automatic chain plate line drive system:

2HP motor, gear box: 80 type tooth box; 2. Speed: 6 m/min, tooling plate speed: 6 m/min; 3. The transportation of tooling plate adopts RF2060, 3 times speed chain.

2. The fuselage line structure of Guangshengde automatic chain plate line:

1. The bracket adopts a 50mm*50mm*2.0mm square pass, the height of the working surface: 740±20 mm; 2. The two sides of the line body are assembled from super-strength 100*118mm triple-speed aluminum profiles; 3. The lighting adopts a 28W single belt Cover T5 energy-saving lamp, lamp holder material adopts 25*50 iron flat pass; 4. Assemble the power supply system, install two-position plug-in seat at each station, 1.2 meters per set; 5. Assemble quick connector, air source triple piece 40SM with 20PH quick connector 7. The craft board adopts aluminum craft card frame with A4 acrylic board; 8. The wind batch chute adopts 28*35 aluminum.

Three, Guangshengde automatic chain board line electrical box configuration:

1. Use Mitsubishi PLC control; 2. Japan Mitsubishi air switch; 3. OMRON relay.

4. The conductive rail of Guangshengde automatic chain plate line:

Integrated conductive rails are installed on both sides of the line body

5. Guangshengde automatic chain plate line tooling board:

1. Size (500)L*(500)W*(25)Tmm; 2. There are no two installations at the bottom of the tooling board; 3. The tooling board uses 25mm density board with anti-static rubber on the surface, conductive copper strips, T-shaped edging ; Install a socket at each end.
